HIGH-TEMP BOX OVEN
ZonHoo high-temp box ovens are compact, high-temperature batch ovens designed for stable thermal cycles in a smaller footprint. This format is ideal when you need elevated temperatures with consistent control, shelf/rack flexibility, and fast deployment near a workcell or lab/pilot area. Typical uses include high-temperature conditioning, controlled preheating, small-batch bake cycles (process-defined), and validation runs before scaling to larger chambers. Each high-temperature box oven is configured to your RFQ: chamber size, temperature range (custom), shelf load capacity, airflow/uniformity approach, ramp/soak recipes, data logging, and safety interlocks—so engineering teams can approve the configuration and procurement teams can quote with clarity.
High-Temp Box Oven Options
High-temp box ovens can be configured around your part size, shelf loading, and temperature profile. Options focus on compact thermal performance, repeatable control, and service-friendly design. Contact ZonHoo for an engineering review aligned to your RFQ and site utilities.
- Compact chamber sizing: working volume matched to part dimensions, clearances, and batch quantity for efficient heat-up and stable control.
- Shelf/rack system: adjustable shelves, trays, and rack supports with shelf load capacity aligned to your fixtures and parts.
- Airflow & uniformity approach: recirculation design, baffles/ducting, and distribution strategy to improve heating consistency across the chamber.
- High-temp insulation & exterior safety: insulation package engineered for elevated temperatures and safer exterior surface temperatures (site-dependent).
- Door & sealing system: reinforced door frame, latch/lock strategy, sealing approach, and door safety interlocks for repeatable cycles.
- Thermal control: programmable ramp/soak recipes, multi-step holds, product thermocouple inputs, and repeatability features.
- Documentation & traceability: data logging, cycle reports, alarm history, and documentation scope aligned to QA/audit needs.
- Safety & interlocks: over-temperature protection, door status logic, airflow/fan proven logic (as configured), and emergency stop integration.
- Serviceability options: access-friendly layout for heaters/fans/sensors to reduce downtime (by configuration).
Key Specs (Custom)
- Temperature Range: Custom high-temperature configuration (process-defined)
- Working Volume: Custom (RFQ-based)
- Shelf Load Capacity: Custom per shelf count and fixture design
- Shelf/Rack System: Adjustable shelves and tray supports (by configuration)
- Airflow Design: Engineered recirculation for compact chambers
- Control Mode: Programmable ramp/soak recipes
- Traceability: Data logging, cycle reports (optional)
- Safety Interlocks: Over-temp protection, door status, emergency stop integration
Typical Applications
- PTFE & polymer sintering trials in a compact high-temp chamber (small batches, stable setpoint control).
- Electronics/electrical component heat conditioning where a small footprint near the workcell matters (bench/compact).
- Inert gas processing (optional setup) for small parts when oxidation control is required (process-defined).
- Aluminum aging treatment trials before scaling to larger ovens (pilot validation runs).
- Curing and forming small components on adjustable shelves (shelf load + repeatability).
- Glass industry sample part preheating for lab/pilot checks (compact chamber uniformity).
- Chemical sample drying / bake in controlled small batches (service-friendly, quick deployment).
- General drying and preheating for small fixtures and assemblies (adjustable shelves, fast changeover).
Standard Features:
- High-temperature chamber construction engineered for repeatable thermal cycles in compact batch processing.
- Adjustable shelf/rack system to support varied part sizes and fixture layouts (by configuration).
- Airflow distribution approach for consistent heating in a compact chamber (baffles/ducting by configuration).
- Programmable controller supporting ramp/soak recipes, alarms, and stable setpoint control.
- Safety system including over-temperature protection, door status logic, and emergency stop interface (site-configurable).
- Service-friendly design for routine inspection and replacement of wear items (heaters, fans, sensors) by configuration.
- Documentation package for quoting and commissioning support (drawings, manuals, and test scope by project).
- Compact high-temp chamber (small footprint)
- Adjustable shelves / rack supports
- Shelf load capacity (process-defined)
- Airflow & uniformity approach (compact chamber)
- Ramp/soak recipes (batch control)
- Data logging / cycle reports (optional)
- Safety interlocks (over-temp, door status)
Let’s talk about how we can support your thermal processing goals. Contact our team to explore the right solution for your needs.
